Automatic Spring Forming Machine , CNC Spring Machine With 100KG Decoiler

Automatic Spring Forming Machine , CNC Spring Machine With 100KG Decoiler

  • Automatic Spring Forming Machine , CNC Spring Machine With 100KG Decoiler
Automatic Spring Forming Machine , CNC Spring Machine With 100KG Decoiler
Product Details:
Place of Origin: Dongguan,China
Brand Name: HYD
Certification: CE / IS09001
Model Number: HYD-20T-3A
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Seaworthy Plywood Case
Delivery Time: 15 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30 sets one week
Contact Now
Detailed Product Description
Wire Diameter: 0.2-2.3mm Axis: Three To Four Axes
Power Supply: 380V 50Hz CNC System: Automatic
Decoiler: 100KG Cutting Tool: Standard
Highlight:

cnc wire bender

,

cnc bending machine





Spring Forming Machine and Cam Spring Machine with 100KG Decoiler



----This machine can be three to six axes according to requirement.



----The spring outside diameter can be adjusted easily by means of setting the program and the outside
diameter axis is working independently.



----Cam can be moved left and right, wire feed length can be change while machine is running



---Optional accessories: spinner,machine hand,servo scissors.





Wire size 0.2-2.3mm
Max feeding speed 141m/min
Direct storage programs 1000
X-axis motor output 2.7KW
Y-axis motor output 2.7KW
Z-axis motor output 1.0KW
Machine size 1400×900×1600mm
Voltage 380V
Weight 700kg





Spring

Automatic Spring Forming Machine , CNC Spring Machine With 100KG Decoiler 0

Automatic Spring Forming Machine , CNC Spring Machine With 100KG Decoiler 1





Our Advantage



HYD is a production and sales combined company, with more than 15 years experience in spring machine



industry, which make us become a experienced and reliable supplier.HYD manufacture CNC spring



machine,wire bending machine,spring coiling machine ect,all of them are CNC,automatic.
