| Place of Origin: | Dongguan,China |
| Brand Name: | HYD |
| Certification: | CE / IS09001 |
| Model Number: | HYD-340 |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case |
| Delivery Time: | 15 Days |
| Payment Terms: | Negotiable |
| Wire Size Range: | 1.0~4.0 Mm | Axis: | 3 Axes |
|---|---|---|---|
| Servo Motor: | Japan Brand | Port: | Shenzhen,China |
| Production Capacity: | 15 Sets One Month | Max Wire Feed: | Unlimited |
| Direction Of Wire Feed: | Right And Left | Max Product Speed: | 400pcs |
| High Light: | High Speed Spring Compression Machine,3 Axis Spring Winder Machine,4.0mm Coil Spring Machine |
||
3 Axis CNC Spring Compression Machine Coil Spring Machine Spring Winder Machine
| HYD-340 Compression Spring Machine Parameters | |
| Model |
HYD-340 |
| Diameter | 1.0~4.0mm |
| Maximum diameter | 65mm |
| The fastest production speed | 400pcs/min |
| Wire feeding length | Unlimited |
| Wire feeding speed | 1200m/min |
| Screen display | Color/Chinese/English |
| Machine size | 1200*850*1650mm |
| Machine weight | 1200kg |
| Power | 220V 50/60HZ |
HYD-340machine features:
1. 2 -5axes high speed coiler
2. Garter spring capacity
3. Edit-on-the-fly
4. Auto edit function
5. Proportional adjustment for OD, Pitch, and number of coils
6. Simple torsion spring available
7. Optional spring gage, air slide, torsion attachment, etc
Samples:
FAQ
1. Q: What information will be helping to get an accurate quotation from us?
A: The customer should provide the related drawings, pictures, industrial voltage, planned output, technical requirements, etc
2. Q: What is the power supply of the machine?
A: The standard power supply in China is 380V, 3P, 50Hz. We also can customized as per requirement.
3. Q: What is the payment term
A: The payment term is 30% deposit as PO confirmation ,and 70% should be finished before the shipment. We also accept other payment terms.
4. Q: What is the delivery time?
A: Normally the delivery time of the machine is 30 days after receiving deposit. But it depends on machine model. Some of them could be shipped within 10 days.
5. Q: What is the guarantee period of the machine?
A: 1 year
